Luxul SW-610-24P-R 24-Port Gb PoE+ L2 L3 Managed Switch with 4 SFP+

The SW-610-24P-R is a 24 port PoE+ rear facing single space rackmount Gigabit switch with 4 SFP+ 10Gb ports (aggregable up to 40Gbps) and a total PoE power budget of 370W. Each of the SFP+ ports can be used alone or aggregated together to allow 20 or 40Gbps throughput to another switch. This L2/L3 switch with 128Gbps switching capacity provides VLAN, QoS and other powerful management features. Up to 16 switches can be grouped in a single pane user-interface allowing easy and comprehensive administration. Variable speed fans for quiet operation. ProWatch Integrated for support of remote monitoring and management.

Included in the box:
SW-610-24P-R switch, power and console cables, rack ears and set of four (4) adhesive feet, quick install guide & regulatory documentation

  • PoE Self-Healing with auto-recovery and power scheduling
  • 24 PoE+ Gigabit Ports
  • 370 Watt total PoE budget
  • Rear-facing ports
  • 4 SFP+ Ports
  • Aggregable up to 40Gbps
  • Rack Mountable
  • Group Manager -Single pane user interface for easy administration of multiple 510 and 610 series switches
Max. Power Consumption 459W @ 100VAC
PoE Power Budget 370W
Switching Capacity 128 Gbps
Connection Type Wired
Layer Support L2
L3
Number of Ports 24
PoE Self Healing Per Port Basis
Port Location Rear
Power Cord US Cord
Power Type AC
ProWatch Type ProWatch Integrated
SPF Port Type 4 x 10 Gigabit
Switch Type Managed
PoE+
VLAN Compliance 802.1Q
Operating Temperature +32°F to +122°F (0°C to +50°C)
Dimensions (H x L x W) 1.75 in (44mm) x 17.4 in (442mm) x 8.3 in (211mm)
Weight 8.4lbs (3.81g)
Warranty Three Year Limited Warranty (Parts & Labor)
